End-to-end BIM workflow for geotechnical engineering – faster, simpler, more reliable
End-to-end BIM workflow for geotechnical engineering – faster, simpler, more reliable
Combine geological model, mass determination, planning of excavations, structural analysis, design and plan creation on the basis of a data model in Revit with FIDES software.
Soil layer model
![](https://www.fides-dvp.de/wp-content/uploads/2023/07/Bodenschichten-auf-Basis-von-Bohrprofilen-und-DGM-1-1024x681.png)
![](https://www.fides-dvp.de/wp-content/uploads/2023/07/bodenmaterial2-1024x686.png)
- Importing and editing DTMs
- Use of drilling profiles and/or DTM
- Library with floor materials according to standard
Creating excavation pits
![](https://www.fides-dvp.de/wp-content/uploads/2023/07/auffuellung-1024x409.png)
![](https://www.fides-dvp.de/wp-content/uploads/2023/07/baugrube-1-1024x651.png)
- Predefined construction pit families (slopes with berm)
- Link between floor slab or 2D lines and excavation possible
- Filling of construction pits
Plan derivation
- Heights
- Inclination and angle dimensioning
- Material labelling
- Slope hatching
![](https://www.fides-dvp.de/wp-content/uploads/2023/07/boeschungsschraffur1-1024x917.png)
![](https://www.fides-dvp.de/wp-content/uploads/2023/07/beschriftung1-1024x540.png)
Calculation of build-up and removal
![](https://www.fides-dvp.de/wp-content/uploads/2023/07/massenermittlung-1024x797.png)
- Mass determination taking into account the construction phases
- Consideration of construction phases possible
Connection to FIDES geotechnics structural analysis programmes
- Export of 2D sections
- Reimport of the calculation results in the form of components such as sheet pile walls, bored pile walls, soldier pile walls, anchors, walings,…
![](https://www.fides-dvp.de/wp-content/uploads/2023/07/walls-verbau-1024x724.png)
![](https://www.fides-dvp.de/wp-content/uploads/2023/07/verbau1-1024x550.png)
![](https://www.fides-dvp.de/wp-content/uploads/2023/07/verbau_spundwand.png)
Construction of axle-based structures
- Fully parameterisable components including Cross slope, variable component heights
- Unfolding of curved component – curved longitudinal section
- Cutting at stations
![](https://www.fides-dvp.de/wp-content/uploads/2023/07/bruecke_schnitt.png)
![](https://www.fides-dvp.de/wp-content/uploads/2023/07/tunnel.png)
![](https://www.fides-dvp.de/wp-content/uploads/2023/07/tunnel_laengsschnitt-1024x533.png)
